DIGITAL MULTIMETER 1030 - KYORITSU (JAPAN)

Model

KEW 1030

DC V

400m/4/40/400/600V (5 Range auto)
±0.8%rdg ±5dgt(400mV - 400V)
±1.0%rdg ±5dgt(600V)

AC V

4/40/400/600V (4 Range auto)
±1.3%rdg ±5dgt (4/40V) (50/60Hz)
±1.6%rdg ±5dgt (400/600V) (50/60Hz)

Ω

400/4k/40k/400k/4M/40MΩ (6 Range auto)
±1.0%rdg ±5dgt (400Ω - 4MΩ)
±2.5%rdg ±5dgt (40MΩ)

Continuity buzzer

Buzzer sounds when resistance is 120Ω or less

Diode test

Test voltage approx. 0.3 - 1.5V

Capacitance

50n/500n/5µ/50µ/100µF (5 Range auto)
±3.5%rdg ±10dgt (50nF)
±3.5%rdg ±5dgt (500n - 50µF)
±4.5%rdg ±5dgt (100µF)

Frequency

5/50/500/5k/50k/200kHz
±0.1%rdg ±5dgt (Measurable input: 1.5Vrms or more)

DUTY

0.1 - 99.9%
±2.5%rdg ±5dgt (Pulse width / Pulse cycle)

Measurement functions

The measured value can be hold by pressing Data hold button

Other functions

When the battery voltage drops to 2.4V±0.2V or less
Built-in

Applicable standards

IEC 61010-1: 2001 CAT III 600V
IEC 61010-031
IEC 61326-1

Power source

Button type battery LR44 (SR44)1.5V × 2

Dimensions

190(L) × 39(W) × 31(D) mm

Weight

Approx. 100g (including batteries)

Included Accessories

Carrying case, LR44 (1.5V) × 2, Instruction manual
