LEVER HOIST 1.6 TON 3 METER - Elephant (Japan)

Bin No : 101038

Brand: Elephant (Japan)

101.000 KWD

9 Items Available

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model	YA-160
Capacity	1.6 ton (3520 lbs)
Chain length	3 meter
Standard lift	5 ft
Hand effort to lift full working load	66 lbf
Dia of load chain	7.1 mm
Net weight	9.07 kg (20 lbs)
Load chain min Breaking load	8.3+
Safety factor	5.3

Rounded lever design for smooth operation when placed against flat surfaces
Grade 105 galvanized load chain, which adheres to the strict German DIN 5684 standard
True one touch free spooling which automatically brakes when a load is applied
Redesigned hooks with tip supporting safety latch
Hoist body has an electro-deposited black finish for corrosion resistance
Ratchet recovery of 16.5^o for 0.8t~1t and 14^o for 1.6t~12t
Internal side plates have hardened steel bushings for excellent load sheave & pinion support
Internal side plates, pinion, pawls, and pawl springs have an electro-deposited coating that helps resist corrosion
Internal disc hub and ratchet wheel are nickel plated for corrosion resistance
Suitable for operation within a -20^o to +130^o C, -4^o to +266^o F temperature range
