SUBMERSIBLE PUMP 1 HP SXG 1000 - SPERONI (ITALY)

PRODUCT DETAILS

• Operating Conditions:
• Liquid temperature up to 35°C (for home use according to EN 60335-2-41)
• Max. liquid temperature: 35°C (for other uses)
• Maximum immersion depth 5 mt.
• Grain size inlet Ø 35 mm
• Min. suction level 65 mm
• Continuous duty
• Motor:
• Single-phase 230V-50Hz (with floater)
• Dual chamber with oil bath motor for cooloiling and bearing lubrification
• Mechanical seal in oil bath
• Permanent split capacitor
• Insulation Class F
• Protection IP 68
• Materials:
• Handle Stainless Steel AISI 304
• Motor casing Stainless Steel AISI 304
• Pump body Cast Iron
• Impeller Stainless Steel AISI 304
• Suction grid Stainless Steel AISI 304
• Shaft with rotor Stainless Steel AISI 304
• Mechanical seal Ceramic/Graphite/NBR
• Applications:
• Drainage submersible stainless steel water pumps with stainless steel impeller
• Able to drain decanting cesspools and to pump waste water for domestic and civil purposes
