HAND PUMP - Holmatro (Holland)

Bin No : 492064

Brand: Holmatro (Holland)

152.000 KWD

Out of Stock Login to save in Wish List

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Article number	100.142.033
Model	PA 04 H 2
Max. working pressure	720 / 72 (bar/Mpa)/10443 psi
Capacity oil tank (effective)	400 cc/13.5 oz
Capacity oil tank	500 cc/16.9 oz
Number of stages	2
First stage output (per stroke)	18.4 cc/0.62 oz
Second stage output (per stroke)	1.4 cc/0.05 oz
First stage pressure range max.	653 psi
First stage pressure range	0 - 45 / 0 - 4.5 (bar/Mpa)
First stage pressure range	0 - 653 psi
Second stage pressure range	45 - 720 / 4.5 - 72 (bar/Mpa)
Second stage pressure range	653 - 10443 psi
Max. operating force	32 kg/70.5 lb
Connection	3/8" NPT female
Operator type	Hand
Double acting optional	No
Weight, ready for use	3.4 kg/7.5 lb
Dimension A	434 mm/17.1 in
Dimension B	135 mm/5.3 in
Dimension C	165 mm/6.5 in
