WINCH GG-500 - KIO WINCH (TAIWAN)

Bin No : 108002

Brand: Kio winch (Taiwan)

380.000 KWD

4 Items Available

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model	GG-500
Lifting capacity (wire rope top layer)	500 kg
First layer	18 m/min
Top layer	23 m/min
Motor rating IP44	1.8 kw x 4 poles
Maximum lifting height	29 m
Wire rope	8 mm x 30 m
Drum dimension width	210 mm
Drum diameter	79 mm
Flange diameter	169 mm
Mounting bolt pattern	255 x 165 mm
Net weight	62 kg

Positive retention of wire rope on to drum
Electromagnetic spring-applied fail safe brake
Heavy duty high efficiency ball bearings on all running surfaces
Planetary gearing for maximum mechanical efficiency
Enclosed drum flange to prevents ropes becoming trapped between drum and support castings quietrunning
