MULTISTAGE CENTRIFUGAL PUMP DHI 4-40M - PENTAIR STA-RITE (ITALY)

Bin No : 5210020

Brand: Pentair (Italy)

145.000 KWD

Out of Stock Login to save in Wish List

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model		DHI 4-40M
Rated voltage		230 V
Motor power		0.94 hp (0.7 kW)
Absorbed power		1.36 hp (1 kW)
Max. capacity		120 l/min (7.2 m³/h)
Max. height		35 m
Max. Suction height		6 m @ 50^oC max.
Connections	Inlet	1.1/4 inch
	Outlet	1.1/4 inch
Max. liquid temperature		90^oC
Max. operating pressure	50^oC	10 bar
	90^oC	6 bar
No load speed		2850 rpm
Pump body		Stainless steel (AISI 316)
Impeller
Intermediate chamber
Motor shaft
Seal-holding flange
Motor casing		Die-cast aluminium
Mechanical seal		Graphite
Counterface		Ceramic
Gaskets		EPDM
Degree of protection		IP 55
Insulation class		F
Made		Italy

Horizontal multi-stage centrifugal pump
High hydraulic performance regarding pressure and capacity
Minimum consumption of electricity
Extremely silent operation
Single phase power supply with permanently activated capacitor and thermal cutout protection incorporated in the motor winding
Applications:

Handling of aggressive liquids
Lifting and distribution of water in domestic systems in continuous or intermittent operation
Pressurization systems
Washing, irriation, gardens, fountains
