HEAVY DUTY FIXED CASTOR 160 MM - BLICKLE (GERMANY)

Bin No : 107185

Brand: Blickle (Germany)

25.400 KWD

3 Items Available

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model	BH-ALB 160K
Wheel Ø	160 mm
Wheel width	50 mm
Load capacity @ 4km/h	750 kg
Load capacity static	1875 kg
Bearing type	Ball bearing
Total height	202 mm
Plate size	140 x 110 mm
Bolt hole spacing	105 x 75 - 80 mm
Bolt hole Ø	11 mm
Temperature resistance	-20^o - 70^oC
Tread and tyre hardness	92 shore A
Weight	2.276 kg
Made	Germany

Pressed steel, zinc-plated, blue-passivated, Cr6-free
Heavy fork and top plate
High chemical resistance to many aggressive substances
Operating temperature: -20°C to +70°C, temporarily up to +90°C, reduced load capacity over +40°C
Tread:
