HAND PUMP PA 38H2 - Holmatro (Holland)

Bin No : 492097

Brand: Holmatro (Holland)

335.000 KWD

2 Items Available

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Details
Articlenumber	100.142.037
Basic specifications
model	PA 38 H 2
max. working pressure	720 / 72 (bar/Mpa)	10443 psi
Performance
number of stages	2
second stage pressure range	45 - 720 / 4.5 - 72 (bar/Mpa)	653 - 10443 psi
first stage pressure range max.		653 psi
first stage pressure range	0 - 45 / 0 - 4.5 (bar/Mpa)	0 - 653 psi
first stage output (per stroke)	42.8 cc	1.45 oz
second stage output (per stroke)	3.1 cc	0.1 oz
max. operating force	35 kg	77.2 lb
capacity oil tank	4150 cc	140.3 oz
capacity oil tank (effective)	3800 cc	128.5 oz
General specifications
operator type	hand
connection	3/8" NPT female
double acting optional	yes
Dimensions, weight and temperature
weight, ready for use	11.4 kg	25.1 lb
