PNEUMATIC GREASE GUN - Pressol (Germany)

Model no

18073

Grease gun connection, pressure-side

M10 x 1

Filling nipple

M10 x 1

Capacity (cm³)

500

Refilling options

400 g grease cartridge, DIN 1284, grease gun filling system or bulk grease

Pressure ratio

50:01:00

Grease supply into the grease gun head

spring operated

Diameter of grease piston (mm)

6

Grease pump piston actuation

Air operated providing a continuous grease flow

Delivery rate/stroke (cm³)

0,8

Recommended air pressure (bar)

6

Min. air pressure (bar)

2

Max. air pressure (bar)

8

Compressed air connection

Female Rectus quick release airline connector, type 26

Pump pressure at 8 bar air pressure (bar)

400

Burst pressure system (bar)

850

Burst pressure grease gun head (bar)

1200

Operation of plunger rod

With L-design handle

Wall thickness of grease gun tube (mm)

1,0

Lacquering

Graphite-grey

Weight (kg)

1,96

Filling nipple (FN),

M 10 x 1 male

Spout, straight,

M 10 x 1, 150 mm

Precision machined coupler,

4

claws

M 10 x 1 female

Dimensions LxWxH (mm)

400 x 170 x 75
