VERTICAL MULTISTAGE CENTRIFUGAL PUMP 3 HP - PENTAIR (ITALY)

Bin No : 5210038

Brand: Pentair (Italy)

485.000 KWD

Out of Stock Login to save in Wish List

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model	PVM 10-6 A
Type	PO4D6010600
Motor	230/400, 50Hz
Power	3 hp ( 2.2 kW)
Maximum pressure	16 bar
Liquid temperature	120^oC max.
Rated flow	10 m³/h
Range of flow rate	5 - 13 m³/h
Height	59 - 32 m
Dimensions	280 x 869 mm
Flange	DN40
Max. ambient temperature	50^oC
Speed of rotation	2900 rpm
Degree of protection	IP 55
Mechanical seal	SiC Standard
Gaskets	EPDM Standard
Insulation class	F
Weight	55 Kg
Made	Italy

Non-self priming vertical multi-stage pump with victaulic or flanged fittings with inlets and outlets of the same size
Construction of stages with impellers, chambers and outlets in stainless steel
Pump cardan shaft and motor shaft are directly coupled according to IEC standard
Equipped with high efficiency motor (IE3)
Cartridge-type mechanical seal for easy maintenance
Applications:
