MULTISTAGE SUBMERSIBLE PUMP 6 INCH 20 HP - SPERONI (ITALY)

Bin No : 5210088

Brand: Speroni (Italy)

750.000 KWD

1 Items Available

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model		SXT 668-08
Rated voltage		400 V - 50 Hz Three-phase
Max. capacity		78 m³/h (1300 l/m)
Max. head height		106 m
Power		20 hp (15 kW)
Max. depth of immersion		350 m
Max. liquid temperature		35^oC
Max. sand content		50 g/m³
Max. Start / hour		10
Motor		Two-pole induction motor (n=2850 min-1)
		Submersible motor in water bath
		Class B Insulation
		IP 68 Protection
		Continuous duty
Motor materials	External casing	Stainless steel AISI 304
	Motor shaft	Stainless steel AISI 304
	Upper body	Cast Iron
	Lower body	Cast Iron
	Mechanical seal	Ceramic / Graphite
Pump materials	External casing	Stainless steel AISI 304
	Motor shaft	Stainless steel AISI 304
	Stages and Impellers	Stainless steel AISI 304
Made		Italy

Multistage submersible water pumps for 6” deep wells (DN 150 mm)
Particularly suitable for civil and industrial purposes, for sprinkler and food irrigation plants, in fire installations and generally for clean water supplying
