HEAVY DUTY WHEEL ALB 160/20K - BLICKLE (GERMANY)

Bin No : 107107

Brand: Blickle (Germany)

23.300 KWD

7 Items Available

*Pictures shown are for illustration purpose only, Actual product may vary.
Usually delivered in 3 business days after order confirmation. Please check Delivery Policy

PRODUCT DETAILS

Model		ALB 160/20K
Wheel	Diameter	160 mm
	Width (T2)	50 mm
Load capacity	4 km/h	750 kg
	6 km/h	600 kg
	10 km/h	370 kg
	16 km/h	280 kg
	Static	1875 kg
Bearing type		Ball bearing
Axle bore Ø		20 mm
Hub keyway (T1)		60 mm
Tread and tyre hardness		92 Shore A
Temperature resistance		-20°C to +70°C
Tread and tyre hardness		80 shore A
Unit weight		1.052 kg
Made		Germany

Tread:

High-quality polyurethane elastomer Blickle Besthane®, hardness 92 Shore A
Very low rolling resistance
High dynamic load capacity
High abrasion resistance
High cut and tear propagation resistance
Colour brown, non-marking, non-staining
Excellent chemical connection with the wheel centre

Wheel centre:

Die-cast aluminium

Other features:

High chemical resistance to many aggressive substances
Operating temperature: -20 °C to +70 °C, temporarily up to +90 °C, reduced load capacity over +40 °C
